RGB Color LED Message Display Screen
1.compare with traditional single color display , it will be more colorful .
2.Have all single color functions, and more save cost .
Send Inquiry
Item | M-series led module and display parameters | |||
LED module | Product | M10 7color | M10 full color | M13.33 |
Module size | 320*160mm | 320*160mm | 320*160mm | |
Pixel density | 10000dots/㎡ | 10000dots/㎡ | 5625dots/㎡ | |
LED lamp | DIP246 | DIP246 | DIP246 | |
Module resolution | 32*16 | 32*16 | 24*12 | |
Module consumption | 20W | 25W | 25W | |
Viewing distance | 10-100m | 5-100m | 14-140m | |
Max.power consumption | 400W/㎡ | 500W/㎡ | 500W/㎡ | |
Drive mode | 1/4scan | 1/8scan | 1/6scan | |
Brightness | 2500cd/㎡ | 3500cd/㎡ | 3500cd/㎡ | |
HUB mode | HUB12 | HUB08 | HUB08 | |
Drive IC | 595 | MBI5188 | JXI5020 | |
LED display | Frame frequency | ≧60Hz/s | ||
Refresh rate | ≧360Hz/s | |||
mttf | >5000hours | |||
lifetime | >100000hours | |||
Defect rate | <0.0001 | |||
Video signal input | RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION etc | |||
Temperature range | Storage:﹣20℃-65℃；Working:﹣20℃~50℃ | |||
Gray Scale/color | 4096 grades for R ,G and B Display ≥16.7M Colors | |||
Working voltage | AC 110/220V | |||
Viewing angle | Horizontal:85º Vertical :45º | |||
Display content | Pictures,Messages etc | |||
Operating Humidity | 10~90% | |||
Storage Humidity | 10~90% | |||
Continue working time | 24hours | |||
control mode | Asynchronization | |||
Advantages:
1.compare with traditional single color display , it will be more colorful .
2.Have all single color functions, and more save cost .
Our company, HELILAI, is one of the best rgb color led message display screen manufacturers and suppliers in China, which offers customers newest and high-quality rgb color led message display screen wholesale service at a low price. Should you be interested in our products, please contact our factory.
