Module Led P8 Smd Full Color
P8 outdoor SMD led module
HELILAI is a national high-tech enterprise, focusing on the research and development, production and sales of LED series application products, and solution manufacturers. At present, the company has: Shenzhen LED Industrial Park covers an area of 68,000 square meters (46,000 square meters for rent and 22,000 square meters for self-use), and 42,000 square meters of Hunan Helilai Smart Display LED Production Base has been put into use.
Main products: intelligent and cultural creative LED display, high-definition small-pitch LED display, indoor and outdoor full-color LED display, LED transparent glass screen, intelligent LED floor tile scene screen, intelligent induction LED interactive screen.
Application field: Committed to intelligent transportation, intelligent security monitoring, radio and television broadcasting, video conference, intelligent advertising media, real estate and commercial display, science and education stadiums, cultural performance stage display, intelligent scene creative display, and other intelligent terminal intelligent display engineering applications.
Our production and equipment
15
years
We have been working in the industry since 2010 years.
108
certificates
We have obtained most of the professional certificates in the industry and insist on international standards of production.
120
awards
We have won a lot of awards for strong creativity
why choose us
why choose our products
1. Waterproof and dustproof: The P8 outdoor module can be used in harsh weather conditions, and will not be affected by rain, snow, sand and other weather conditions, and is suitable for use in various outdoor scenarios.
2. High brightness: The brightness of the P8 outdoor module is up to 7000nits, which can clearly display the content even in strong sunlight, providing a better effect for outdoor advertising.
3. Low energy consumption: The P8 outdoor module adopts advanced energy-saving technology, which has low energy consumption and long service life.
4. Good display effect: P8 outdoor module has the advantages of high definition, high contrast, high color reproduction and wide viewing angle, etc., and the display effect is clear and realistic, showing bright and vivid colors.
5. Easy installation: The P8 outdoor module is fast to build, simple and convenient to install, and can be spliced in a variety of shapes, such as arc, circle, trapezoid. which can meet various outdoor advertising needs.
6. Wide range of applications: P8 outdoor modules can be widely used in various places, such as squares, stadiums, shopping malls, stations, airports.
Products specifications
| 1 | LED types | SMD3535 | ||||||
| 2 | Pixel pitches(mm) | 8mm | ||||||
| 3 | Pixel composition | 1RGB | ||||||
| 1 | Module resolution(W*H) | 40*20dots | ||||||
| 2 | Module size(W*H) | (W)320mm×( L)160mm | ||||||
| 3 | Mark | Yes | ||||||
| 4 | LED brand | Hongsheng | ||||||
| 5 | Drive IC | ICN2037/16380IC | ||||||
| 6 | Pixel density | 15625pixels/ m² | ||||||
| 7 | Brightness(CCT 6500K) | >5000cd/ m²(adjustable) | ||||||
| 8 | Level/vertical angle | 120°/120° | ||||||
| 9 | Flatness | ≥98% | ||||||
| 10 | Gray scale | red,green,blue all≥12bit | ||||||
| 11 | Scan mode | 1/5scan | ||||||
| 12 | Refresh frame frequency | 60Hz/s | ||||||
| 13 | Refresh rate | 1920-3840Hz/s | ||||||
| 14 | Max.power consumption | 40W/PCS | ||||||
| 15 | Continuous working hours | ≥7×24hrs,(continuously display available) | ||||||
| 16 | MBTF | ≥10000 hours | ||||||
| 17 | LED life time | 100,000 hours | ||||||
| 18 | Failure pixel rate | ≤0.0001 | ||||||
| 19 | Operating Temp. | -10℃～60℃ | ||||||
| 20 | Humidity Range | 10％～95％RH,Non-condensing | ||||||
| 21 | Screen color temperature | 12000K(adjustable) | ||||||
| 22 | Brightness adjust | Manually/Automatic/Program control | ||||||
| 23 | Correction | Brightness and chroma correct point by point | ||||||
| 24 | Control method | Synchronous/Asynchronous control | ||||||
| 25 | Working voltage | AC：110-220,50~60Hz/s | ||||||
Products certificates
Products packages
Products application
Transportation Industry:
Used at transportation hubs such as highways, airports, and railway stations for signage and billboards, providing clear traffic information and advertising.
Displays surveillance video footage in real-time to support traffic management and safety monitoring.
Electric Power Industry:
Display screens are set up around electric power facilities to showcase power supply information, safety warnings, and other relevant details.
Water Conservancy Industry:
Display screens are installed near water conservancy facilities such as reservoirs and rivers to display water level information, flood control warnings, and other critical data.
Security Field:
Used in public places such as communities, schools, and hospitals for safety monitoring and disseminating warning information.
Real-time surveillance footage is displayed in security monitoring centers to enhance safety precautions.
Urban Management:
Display screens are set up in public places such as city squares, parks, and commercial districts to showcase city image, public announcements, advertising, and other relevant information.
They support the construction of smart cities by providing real-time information on traffic, weather, news, and more.
Radio and Television Industry:
Used by media organizations such as television stations and radio stations for outdoor advertising and information dissemination.
Commercial Advertising:
Display screens are installed in commercial venues such as shopping centers, malls, hotels, and restaurants to display advertisements, promotional activities, and other marketing content.
Our service
Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offered.
5. Other requireed services such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
After-sale service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 24 months.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
Payment & shipping
Common Problem
What is P8 LED ?
P8 LED is a high-brightness, high-definition LED display. It uses SMD3535LED lamp beads, the lamp bead spacing is 8mm, and has the characteristics of high resolution, high contrast, high brightness and so on
What is the price of P8 LED ?
The raw materials are different, the price is different, and the price needs to be given according to the specific order.
What is P10 led module ?
P10 LED module is a high-brightness, high-definition LED display module, which is widely used in commercial advertising, sports events, stage shows and other fields. It has the advantages of low power consumption, long life, easy installation, and low maintenance cost.
What is outdoor led screen ?
Outdoor LED display is a display composed of LED lights, which plays a role in displaying advertising, information, video and other content in an outdoor environment.
